Actuator ADC120 Generator Part Electric Valve Linear Speed Actuator Waterproof Hydraulic Brake Controller

key words: electric actuator
appliction: diesel generator
it match ESD55000E.ESD5111 Speed gorvener to control engine speed. good universal performance.longevity.stability.
PERFORMANCE:
Available Torque Max1.0Lb-ft(1.4Nm)
Maximum Operating Shaft Angular Travel 25+/- 1degree CW/CCW
1A at 24VDC
3 A at 24VDC
ENVIROMENTAL:
Temperature Range -54 to 95
Relative Humidity up to 100%
All Surface finishes Fungus proof and corrosion resistant
PHISICAL:
Weight 2.3 kg
Mounting Any position, electrical connector at the top preferred
RELIABILITY:
Vibration up to 20G @50-500 Hz
Testing 100% Tested
MATING HARDWARE
Connector Supplied With Actuator
Lever LE1500-2
Rod End Bearings(to attach a 12#20 HD linkage rod to lever) BR100(Right Hand)
BR101(Left Hand)
Wiring Harness ADC120 4ft. Harness supplied with actuator, other length available from Actuator
colour:gray
Material:metal
size:16*16*14cm
Package Contents:
1*Electric actuator
Only the above package content, other products are not included.
Note: Light shooting and different displays may cause the color of the item in the picture a little different from the real thing. The measurement allowed error is +/- 1-3cm.
