Generator Battery Charger BAC2405 BAC2405CF 5A 24V
Generator Battery Charger BAC2405 BAC2405CF 5A 24V Generator Battery Charger BAC2405 BAC2405CF 5A 24V Generator Battery Charger BAC2405 BAC2405CF 5A 24V Generator Battery Charger BAC2405 BAC2405CF 5A 24V

Generator Battery Charger BAC2405 BAC2405CF 5A 24V

Product ID : BAC2405CF
Product Attributes :
Product number
BAC2405
MAX input voltage
90 ~ 280V
AC Frequecy
50/60HZ
Voltage
24V
Temperature
12 mouths
MaX current
5A
Product Description

BAC2405 battery charger adopts the latest switching power supply device, which is specially

designed for the charging characteristics of lead-acid batteries for engine starting. It is suitable

for long-term supplementary charging (floating charge)of lead-acid batteries. This charger is

suitable for 24V battery pack.

Performance characteristics


1. Using switching power supply structure, wide input AC voltage range, small size, light weight and high efficiency.

2. It adopts two-stage charging method (that is, constant current first and constant voltage method) for automatic charging,
and fully charges the battery according to the charging characteristics of the battery, which can prevent lead-acid batteries
from being overcharged and can maximize the battery life.

3. With short circuit and reverse connection protection.

4. The charging voltage and current value can be adjusted at the scene through a potentiometer.

5.Suitable for 24V battery pack charging, rated charging current is 5A.

6. Status LED display: power indication, charging indication.
